IPM OP242CD Transfer Pump (2:1 Ratio) (820303)

SKU: 820303

In Stock

$1,890.00

IPM OP242CD Transfer Pump (2:1 ratio)

Air Operated Fluid Pump which is specially designed for corrosive materials. Commonly used for low ceiling applications

Features

Fully air operated
2 ball piston design provides uniform positive displacement
Extremely durable pump with long life packing
Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

For 55 gallons steel drum
This pump is designed for the convenience of operator to take out/shaft in the pump when working inside the truck, due to smaller diameter at the bottom of the pump
For fluid transfer and feed
Mobile air spray machines

Typical Fluids Handled

Polyurethanes (Isocyanate or Polyol)
All kinds of paints
Coatings
Mold release
Stains
Varnishes
Lacqueurs
Lubricants
Water

Technical Information

Fluid Ratio : 2:1
Max Output Flow Int : 7.5 gpm(28.4 lpm)
Max Output Flow Cont : 5.0 gpm(18.9 Ipm)
Max Output Pressure : 360 psi (24.8 bar)
Max Air Input Pressure : 180 psi (12.4 bar)
Air Inlet Port : 1/4 npt(f)
Fluid Outlet Port : 3/4 npt(f)
Rod Piston Packings : Telfon®
Other Seals : Viton®
Rod Cylinder : Stainless Steel
Other Wetted Parts : Stainless Steel
Weight : 11.8kg
Package : 6"x6"x58"(150mmx150mmx147cm)11.8Kg

AIR SECTION REBUILD KIT: 601018

FLUID SECTION REBUILD KIT: 601035
