PMC PHX2 PROPORTIONER, 5HP, 220V, 3PH, 120T, 14KW (106544)
PHX-2 PMC Proportioner, 5HP, 220V, 3PH, 120T, 14KW
PHX-2 3000 psi (207 bar) – Ideal for Use in Plural Component Coatings Applications
Offering the “Most Affordable Hydraulic Proportioner with Horizontal Pumps”
Includes Pressure Balance Control System, Inlet Monitoring and Count Down Shutoff
Output |
1.7 gal/min (6.43 liters/min) |
Max Working Pressure |
3,000 psi (206 bar) |
Max Hose Length |
210 ft (64 m) w/70V Trans 310 ft (94.5 m) w/90V Trans 410 ft (121.9 m) w/120V Trans |
Heater Wattage |
14,000 watts Total (Single Heater) |
Hose Heating Power |
70 Volt, 90 Volt or 120 Volt |
Max Fluid Temperature |
190 F (87.7 C) |
Air Consumption
|
Not Applicable |
Main Voltage |
1 x 208-230V, 50/60 Hz |
Electrical @ |
108A–14,000W heaters |
Main Voltage |
3 x 208-230V, 50/60 Hz, 3 x 380V, 50/60 Hz |
Electrical @ |
69A–14,000W heaters |
Dimensions |
44”w x 22”d x 54”h (111 cm x 55 cm x 137 cm) |
Weight |
415 lbs (188 kg |
