IPM OP232C Transfer Pump (2:1 Ratio) (820301)
IPM

IPM OP232C Transfer Pump (2:1 Ratio) (820301)

SKU: 820301
Categories : Home page
In Stock
$1,846.00

IPM OP232C Transfer Pump (2:1 ratio)


Air Operated Fluid Pump which is specially designed for corrosive materials.

Features

  • Fully air operated.
  • 2 ball piston design provides uniform positive displacement.
  • Extremely durable pump with long life packing.
  • Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

  • For standard 55 gallons steel drum
  • Foam chemical supply
  • Spray gun supply
  • Dispensing valve supply
  • Cleaning chemical supply
  • Fluid transfer

Typical Fluids Handled

  • Solvent based paints
  • Water based paints (SST models)
  • Solvents
  • Cleaning chemical supply
  • Chemicals
  • Catalysts
  • Isocyanates
  • Adhesives
  • Resins
  • Polyurethanes
  • Polyureas

Technical Information

Fluid Ratio: 2:1
Max Output Flow Int: 7.5 gpm(28.4 lpm)
Max Output Flow Cont: 5.0 gpm(18.9 Ipm)
Max Output Pressure: 360 psi (24.8 bar)
Max Air Input Pressure: 180 psi (12.4 bar)
Air Inlet Port: 1/4 npt(f)
Fluid Outlet Port: 3/4 npt(f)
Rod Piston Packings: UHMU PE or Telfon®
Other Seals: Viton®
Rod Cylinder: Stainless Steel
Other Wetted Parts: Stainless Steel
Weight: 24 Ibs.(11.8 Kg.)
Package: 6"x6"x58" (152mmx152mmx147cm) 26 Ibs.(11.8 Kg.)
 AIR SECTION REBUILD KIT: 601018
FLUID SECTION REBUILD KIT: 601035
