BOSS 6/12 PROPORTIONER SINGLE PHASE (BOSS612K) (BOSS-6-12K)

BOSS

BOSS 6/12 PROPORTIONER SINGLE PHASE (BOSS612K) (BOSS-6-12K)

SKU: BOSS-6-12K

In Stock

$15,250.00

BOSS 6/12k Proportioner- Single Phase

Boss 6/12K 3 Phase Proportioner is also available

Features

Dual heating blocks for the ISO and Resin provides extra heating elements for colder climates
Simple 240V single-phase system. The electrical system is all breaker and relay design, for easy repairs if needed.
Heating elements are much larger than those in competitive machines, capable of heating more material faster than other proportioners
Designed to spray polyurethane or polyurea – Foam, bed liners, sealants, slab jacking, etc.
3,000 psi maximum working pressure
Air-driven machine with 6” motor
Higher pressure output than 5” series
Powerful and larger heating elements for more material to reach desired Delta-T
Easily attainable components to minimize downtime
Easy to power on and off
Digital heating controls
Hose heat transformer for up to 400 feet of hose

Technical Data

Preheat 12,000 watts
195 degrees maximum fluid temperature
32 lb/min. maximum output
.0500 gal/cycle output each cycle (A & B pumps)
Fluid inlet ¾” npt with ½” npt outlet
Component A (ISO) #6 (3/8”) JIC with #5 (5/16”) JIC adapter
Component B (Resin) #6 (3/8”) JIC with #6 (3/8”) JIC adapter
Fluid circulation ¼” with thermoplastic tubing (3,000 psi)
Parts contacting fluid: stainless steel, zinc plated, carbon steel, aluminum, chrome, brass, PTFE, Viton O-rings
Weight – 301 lbs.
Dimensions – D: 24” x W: 28” x H: 52”
Air requirements – 17 cfm @ 150 psi; requires at least 26-30 cfm @ 100 psi, which is easily acquired with a 18 hp gas air compressor or 10 hp electric air compressor

Quantity

TOPS + T-Shirt

Size	Bust	Waist	Hips	US/CAN
XS	32-33	24-25	35-36	0/1
S	34-35	26-27	37-38	3/5
M	36-37	28-29	39-40	7/9
L	38.5-40	30.5-32	41.5-43	11/13
XL	41 1/2	33 1/2	44 1/2	15
1X	44-45.5	37-38.5	47-48.5	14/16
2X	47-49	40-42	50-52	18/20
3X	51-53	44-46	54-56	22/24

Pants / Shorts / Skirts

Size EU	Size UK	Waist	Hip
XS / 34	6	78-82	87-91
S / 36	8	82-86	91-95
M / 38	10	86-90	95-99
L / 40	12	90-94	99-103
XL / 42	14	90-98	103-107

Tops

Size EU	Size UK	Chest	Waist	Hip
XS / 34	6	78-82	60-64	87-91
S / 36	8	82-86	64-68	91-95
M / 38	10	86-90	68-72	95-99
L / 40	12	90-94	72-76	99-103
XL / 42	14	90-98	76-80	103-107

Pants / Shorts / Skirts

Size EU	Size UK	Waist	Hip
XS / 34	6	78-82	87-91
S / 36	8	82-86	91-95
M / 38	10	86-90	95-99
L / 40	12	90-94	99-103
XL / 42	14	90-98	103-107

BOSS 6/12k Proportioner- Single Phase

Boss 6/12K 3 Phase Proportioner is also available

Features

Dual heating blocks for the ISO and Resin provides extra heating elements for colder climates
Simple 240V single-phase system. The electrical system is all breaker and relay design, for easy repairs if needed.
Heating elements are much larger than those in competitive machines, capable of heating more material faster than other proportioners
Designed to spray polyurethane or polyurea – Foam, bed liners, sealants, slab jacking, etc.
3,000 psi maximum working pressure
Air-driven machine with 6” motor
Higher pressure output than 5” series
Powerful and larger heating elements for more material to reach desired Delta-T
Easily attainable components to minimize downtime
Easy to power on and off
Digital heating controls
Hose heat transformer for up to 400 feet of hose

Technical Data

Preheat 12,000 watts
195 degrees maximum fluid temperature
32 lb/min. maximum output
.0500 gal/cycle output each cycle (A & B pumps)
Fluid inlet ¾” npt with ½” npt outlet
Component A (ISO) #6 (3/8”) JIC with #5 (5/16”) JIC adapter
Component B (Resin) #6 (3/8”) JIC with #6 (3/8”) JIC adapter
Fluid circulation ¼” with thermoplastic tubing (3,000 psi)
Parts contacting fluid: stainless steel, zinc plated, carbon steel, aluminum, chrome, brass, PTFE, Viton O-rings
Weight – 301 lbs.
Dimensions – D: 24” x W: 28” x H: 52”
Air requirements – 17 cfm @ 150 psi; requires at least 26-30 cfm @ 100 psi, which is easily acquired with a 18 hp gas air compressor or 10 hp electric air compressor
