In:Pulse Ratio Control System

Self-Adjusting Ratio Control for Low-Pressure Spray Foam Systems

No matter what spray foam system you use, being on-ratio is key for the chemical to mix – like the way the material supplier intended. Graco In:Pulse will help provide better yield and on-ratio product and eliminate the need for calibration.In:Pulse provides real-time volumetric ratio control. Throughout the day, as the ratio mix changes due to ambient conditions, tank pressures, nitrogen pressures, etc., In:Pulse will self-adjust to ensure you spray on-ratio – every time.

How it Works

  1. Display Module:Compares ratio of the “A” and “B” chemicals and makes adjustments on the fly to keep you in control
  2. Pressure Regulator:Adjusts "A" chemical pressure to keep you on ratio
  3. Flow Meter (A side):Measures the flow of "A" chemical
  4. Flow Meter (B side):Measures the flow of "B" chemical

Low pressure (LP) spray foam systems play an instrumental role to an insulation contractor. LP systems are typically portable, convenient, and at times a more cost effective solution than sending out a high pressure rig. LP systems are ideal for some small, touch-up and repair jobs, as well as some in-plant foam applications.





Display Module

  • Easy to use
  • Real time ratio information
  • Tank level indicator
  • Historical spray volumes for lifetime and job
  • Error display and history

Flow Meters

  • Volumetric flow meters ensure optimum yield
  • Hands free ratio control
  • Maintains ratio accuracy within 5%

In:Pulse Heated Hoses

  • Automatic heat setting to 75°F
  • Plugs into a standard 110V/15A outlet
  • Hits temperature set point in five minutes*
  • Lightweight and flexible
  • Comes in 50 foot sections
  • Unheated hose sets are available
  • * Assumes chemical is stored at 55°F

Remote Alarm

  • Alerts operator to any off-ratio or low tank level conditions
  • Alarm built into the hose bundle
  • Alarm placed near gun for operator convenience

Ordering Information:

17P038 - Complete low pressure spray foam package for E84 Class 1 (A) Spray Foam Systems, includes:
Ratio control kit (17L851), 50 ft heated hose set with buzzer cable (17L891), 50 ft unheated hose set with buzzer cable (17L893),6 ft whip hose (17P226)

17P039 - Complete low pressure spray foam package for Appendix X Spray Foam Systems, includes:
Ratio control kit (17L851), 50 ft heated hose set with buzzer cable (17L892), 50 ft unheated hose set with buzzer cable (17L894),6 ft whip hose (17P225)

17L851 Ratio control kit, includes:
Meters, display, pressure regulator, remote alarm and mounting bracket
