IPM

IPM IP10S Transfer Pump (10:1 Ratio) (840903)

SKU: 840903

In Stock

$3,400.00

IPMIP-10S Transfer Pump (10:1 ratio)

Heavy duty air operated fluid pump designed for thicker viscosity and a wider variety of materials.

Features

Fully air operated
2 ball piston design provides uniform positive displacement
Extremely durable pump with long life packing
Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

For wall mount or 5 gallon pail application
Fluid transfer and supply for application equipment
Paint circulating
Cleaning chemical supply
Air-Assisted Airless spray finishing (IP-10)
Wood furniture and fixture finishing
Fabricated metal finishing
Aircraft finishing
Farm and construction equipment finishing

Typical Fluids Handled

Solvent based paints
Water based paints
Texture coatings
Cleaning fluids
Adhesives and sealants
Urethanes
Epoxies
Acrylics
Silicones
Polysulfides
PVC
Polyesters
Inks (IP-10)
Varnishes (IP-10)
Colorants (IP-10)
Single and plural component primers (IP-10)
Single and plural component topcoats (IP-10)

Technical Information

Fluid Ratio : 10:1
Max Output Flow Cont : 3.0 gpm(11.4 ipm)
Max Output Pressure : 1800 psi (124 bar)
Max Air Input Pressure : 180 psi (12.4 bar)
Air Inlet Port : 1/2" npt(f)
Fluid Outlet Port : 3/4"npt (f)
Rod Piston Packings : UHMWPE/Teflon®
Other Seals : Rubber
Rod Cylinder : Stainless Steel
Other Wetted Parts : Stainless Steel
Weight Stubby Drum : 17.2Kg
Package : 8.5"x8.5"x31.5"(215mmx215mmx80cm)17.2Kg

Quantity

IPMIP-10S Transfer Pump (10:1 ratio)

Heavy duty air operated fluid pump designed for thicker viscosity and a wider variety of materials.

Features

Fully air operated
2 ball piston design provides uniform positive displacement
Extremely durable pump with long life packing
Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

For wall mount or 5 gallon pail application
Fluid transfer and supply for application equipment
Paint circulating
Cleaning chemical supply
Air-Assisted Airless spray finishing (IP-10)
Wood furniture and fixture finishing
Fabricated metal finishing
Aircraft finishing
Farm and construction equipment finishing

Typical Fluids Handled

Solvent based paints
Water based paints
Texture coatings
Cleaning fluids
Adhesives and sealants
Urethanes
Epoxies
Acrylics
Silicones
Polysulfides
PVC
Polyesters
Inks (IP-10)
Varnishes (IP-10)
Colorants (IP-10)
Single and plural component primers (IP-10)
Single and plural component topcoats (IP-10)

Technical Information
