IP30 Transfer Pump (30:1 Ratio) (841101)
IPM

IP30 Transfer Pump (30:1 Ratio) (841101)

SKU: 841101
Categories :
In Stock
$4,301.00

IMP IP-30 Transfer Pump (30:1 Ratio)


Heavy duty air operated fluid pump designed for thicker viscosity and a wider variety of materials.

Features

  • Fully air operated
  • 2 ball piston design provides uniform positive displacement
  • Extremely durable pump with long life packing
  • Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

  • For wall mount or 5 gallon pail application
  • For fluid transfer and feed
  • Mobile air spray machines

Typical Fluids Handled

  • Polyurethanes (Isocyanate or Polyol)
  • All kinds of paints
  • Coatings
  • Mold release
  • Stains
  • Varnishes
  • Lacqueurs
  • Lubricants
  • Water

Technical Information

Fluid Ratio : 30:1
Max Output Flow Cont : 1.0 gpm (3.79 ipm)
Max Output Pressure : 5400 psi (372.4 bar)
Max Air Input Pressure : 180 psi (12.4 bar)
Air Inlet Port : 1/2" npt(f)
Fluid Outlet Port : 3/8"npt(f)
Rod Piston Packings : UHMWPE/Teflon®
Other Seals : Rubber
Rod Cylinder : Stainless Steel
Other Wetted Parts : Stainless Steel
Weight Stubby Drum : 16.6Kg
Package : 8.5"x8.5"x35.4"(215mm x 215mm x 90cm) 16.6 Kg

Quantity

IMP IP-30 Transfer Pump (30:1 Ratio)


Heavy duty air operated fluid pump designed for thicker viscosity and a wider variety of materials.

Features

  • Fully air operated
  • 2 ball piston design provides uniform positive displacement
  • Extremely durable pump with long life packing
  • Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

  • For wall mount or 5 gallon pail application
  • For fluid transfer and feed
  • Mobile air spray machines

Typical Fluids Handled

  • Polyurethanes (Isocyanate or Polyol)
  • All kinds of paints
  • Coatings
  • Mold release
  • Stains
  • Varnishes
  • Lacqueurs
  • Lubricants
  • Water

Technical Information

Fluid Ratio : 30:1
Max Output Flow Cont : 1.0 gpm (3.79 ipm)
Max Output Pressure : 5400 psi (372.4 bar)
Max Air Input Pressure : 180 psi (12.4 bar)
Air Inlet Port : 1/2" npt(f)
Fluid Outlet Port : 3/8"npt(f)
Rod Piston Packings : UHMWPE/Teflon®
Other Seals : Rubber
Rod Cylinder : Stainless Steel
Other Wetted Parts : Stainless Steel
Weight Stubby Drum : 16.6Kg
Package : 8.5"x8.5"x35.4"(215mm x 215mm x 90cm) 16.6 Kg
