PMC PH2 PROPORTIONER, 3HP, 220V, 3PH, 120T, 9KW (105243)
PMC

PMC PH2 PROPORTIONER, 3HP, 220V, 3PH, 120T, 9KW (105243)

SKU: 105243
Categories : Home page
In Stock
$30,324.00

PH-2 PMC Proportioner


 PH-2 2000 psi (138 bar) – Ideal for Residential Foam Insulation Applications

Offering the “Most Affordable Hydraulic Proportioner with Horizontal Pumps”
Includes Pressure Balance Control System, Inlet Monitoring and Count Down Shutoff



Output

28 lbs/min

(12.70 kg/min)

Max Working Pressure

2,000 psi (138 bar)

Max Hose Length

210 ft (64 m) w/70V Trans

310 ft (94.5 m) w/90V Trans

410 ft (121.9 m) w/120V Trans

Heater Wattage

7,500 watts Total (Single htr)

9,000 watts Total (Single htr)

10,500 watts Total (Single htr)

Hose Heating Power

70 Volt, 90 Volt or 120 Volt

Max Fluid Temperature

190 °F (87.7 °C)

Air Consumption
@ 100 psi (6.9 bar)

Not Applicable

Main Voltage

1 x 208-230V, 60 Hz

Electrical @

61A–7,500W heaters

67A–9,000W heaters

72A–10,500W heaters

Main Voltage

3 x 208-230V, 50/60 Hz,

3 x 380V, 50/60 Hz

Electrical @

40A–7,500W heaters

46A–9,000W heaters

51A–10,500W heaters

Dimensions

44”w x 22”d x 54”h

(111 cm x 55 cm x 137 cm)

Weight

415 lbs

(188 kg)
Quantity

Size Chart (Men)

TOPS + T-Shirt
Size Bust Waist Hips US/CAN
XS 32-33 24-25 35-36 0/1
S 34-35 26-27 37-38 3/5
M 36-37 28-29 39-40 7/9
L 38.5-40 30.5-32 41.5-43 11/13
XL 41 1/2 33 1/2 44 1/2 15
1X 44-45.5 37-38.5 47-48.5 14/16
2X 47-49 40-42 50-52 18/20
3X 51-53 44-46 54-56 22/24

Pants / Shorts / Skirts
Size EU Size UK Waist Hip
XS / 34 6 78-82 87-91
S / 36 8 82-86 91-95
M / 38 10 86-90 95-99
L / 40 12 90-94 99-103
XL / 42 14 90-98 103-107

Size Chart (Men)

Tops
Size EU Size UK Chest Waist Hip
XS / 34 6 78-82 60-64 87-91
S / 36 8 82-86 64-68 91-95
M / 38 10 86-90 68-72 95-99
L / 40 12 90-94 72-76 99-103
XL / 42 14 90-98 76-80 103-107

Pants / Shorts / Skirts
Size EU Size UK Waist Hip
XS / 34 6 78-82 87-91
S / 36 8 82-86 91-95
M / 38 10 86-90 95-99
L / 40 12 90-94 99-103
XL / 42 14 90-98 103-107

PH-2 PMC Proportioner


 PH-2 2000 psi (138 bar) – Ideal for Residential Foam Insulation Applications

Offering the “Most Affordable Hydraulic Proportioner with Horizontal Pumps”
Includes Pressure Balance Control System, Inlet Monitoring and Count Down Shutoff



Output

28 lbs/min

(12.70 kg/min)

Max Working Pressure

2,000 psi (138 bar)

Max Hose Length

210 ft (64 m) w/70V Trans

310 ft (94.5 m) w/90V Trans

410 ft (121.9 m) w/120V Trans

Heater Wattage

7,500 watts Total (Single htr)

9,000 watts Total (Single htr)

10,500 watts Total (Single htr)

Hose Heating Power

70 Volt, 90 Volt or 120 Volt

Max Fluid Temperature

190 °F (87.7 °C)

Air Consumption
@ 100 psi (6.9 bar)

Not Applicable

Main Voltage

1 x 208-230V, 60 Hz

Electrical @

61A–7,500W heaters

67A–9,000W heaters

72A–10,500W heaters

Main Voltage

3 x 208-230V, 50/60 Hz,

3 x 380V, 50/60 Hz

Electrical @

40A–7,500W heaters

46A–9,000W heaters

51A–10,500W heaters

Dimensions

44”w x 22”d x 54”h

(111 cm x 55 cm x 137 cm)

Weight

415 lbs

(188 kg)
