BOSS 5/12k Proportioner- Single Phase

Boss 5/12K Proportioner 3 Phase is also available

Features

• Dual heating blocks for the ISO and Resin provides extra heating elements for colder climates
• Simple 240V single-phase system. The electrical system is all breaker and relay design, for easy repairs if needed.
• Heating elements are much larger than those in competitive machines, capable of heating more material faster than other proportioners
• Air-driven machine with 5” motor
• Easily attainable components to minimize downtime
• Easy to power on and off
• Digital heating controls
• Hose heat transformer for up to 400 feet of hose
• Designed to spray up to 2,000 psi

Technical Data

• Preheat 12,000 watts
• 195 degrees maximum fluid temperature
• 32 lb/min. maximum output
• .0500 gal/cycle output each cycle (A & B pumps)
• Fluid inlet ¾” npt with ½” npt outlet
• Component A (ISO) #6 (3/8”) JIC with #5 (5/16”) JIC adapter
• Component B (Resin) #6 (3/8”) JIC with #6 (3/8”) JIC adapter
• Fluid circulation ¼” with thermoplastic tubing (3,000 psi)
• Parts contacting fluid: stainless steel, zinc plated, carbon steel, aluminum, chrome, brass, PTFE, Viton O-rings
• Weight – 301 lbs.
• Dimensions – D: 24” x W: 28” x H: 52”
• Air requirements – 11 cfm @ 150 psi; requires at least 24 cfm @ 175 psi, which is easily acquired with a 13 hp gas air compressor or 7.5 electric air compressor
